Nozzles for welding

We supply products such as ceramic nozzles in various shapes and sizes, for diverse types of TIG welding torches and for semi-automatic
and automatic welding machines.

It is also possible to manufacture nozzles of all shapes and sizes based of your drawings.

Following, please find a list of our standard nozzles (status October 01 2011).

Ser. No. Product No. External dimensions of nozzle
Length
mm
Diameter of fitting bore
mm
Diameter of exit bore
mm
1 KS1.43 43 18 (thread) 9
2 KS2.47 47 18 (thread) 11.5
3 KS3.54 54 27 (thread) 9
4 KS4.54 54 27 (thread) 11.8
5 KS5.54 54 27 (thread) 14.5
6 KS19.46 46 14 8
7 KS22.255 25.5 18 (thread) 10
8 KS24.65 65 17 15
9 KS26.75 75 16 (thread) 22
